Lightweight Corrosion Resistant Aluminum Perforated Sheet Optional Color Coated
商品の詳細:
| 起源の場所: | 中国 |
| ブランド名: | HUIYI |
| 証明: | ISO 9001, ASTM B117, AAMA 2605 |
| モデル番号: | アルミ穴あきシート |
| ドキュメント: | HUIYI CATALOGUE.pdf |
お支払配送条件:
| 最小注文数量: | 25トン |
|---|---|
| 価格: | Negotiated Price, USD/MT |
| パッケージの詳細: | PE防水フィルム+クラフト紙+エッジガード付き燻蒸パレット |
| 受渡し時間: | 15-45DAYS |
| 支払条件: | L/C、T/T、D/P |
| 供給の能力: | 月産5000トン |
|
詳細情報 |
|||
| 製品名: | アルミ穴あきシート | コーティングの種類: | PVDF / 粉体塗装 / ミル仕上げ |
|---|---|---|---|
| 膜厚: | PVDF ≥30μm;粉末 60～80μm | シートエッジ処理: | ミルエッジ / トリムエッジ |
| 開口面積率: | 15% - 75% (カスタマイズ可能) | 降伏強さ: | ≧125MPa |
| 張力強度 (Rm): | 130～152MPa | 主な機能: | 軽量かつ高耐食性 |
製品の説明
| Base Material | 3003 Aluminum Alloy (Al-Mn series) |
|---|---|
| Alloy Density | Approx. 2.73 g/cm³ |
| Standard Thickness | 0.8mm (Available Range: 0.5mm - 6.0mm) |
| Standard Sheet Size | 1220mm x 3050mm (Custom sizes available upon request) |
| Hole Shape & Pattern | Round Holes, Staggered 60° Pattern |
| Hole Diameter | 0.8mm - 10mm |
| Surface Treatment | Mill Finish, Powder Coating, PVDF Coating |
| Corrosion Resistance | Compliant with ASTM B117 Salt Spray Testing standards |
· Architectural Façades & Cladding: Used as ventilated rain screens and decorative exterior skins, the panels provide solar shading while allowing natural ventilation, significantly reducing building energy loads.
· Interior Design & Ceilings: Ideal for modern ceiling systems, acoustic baffles, and room partitions. The perforations help diffuse sound and integrate seamlessly with HVAC and lighting systems, enhancing both spatial aesthetics and functional comfort.
· Ventilation & Sunscreens: Serves as durable sunshades and protective covers for HVAC units. The open area allows for efficient airflow and natural light diffusion while preventing UV degradation.
· Industrial Filtration & Guards: Employed as machinery safety guards, filtration screens, and protective grilles where high visibility, airflow, and impact resistance are required.
Triple-Shield Packaging
PE waterproof film with desiccants + kraft paper outer wrap + 15mm fumigated wooden pallets with EPE edge guards.
Global Logistics
FOB/CIF from Chinese ports; 15-20 day delivery for Asia, 30-45 days globally.
Quality Assurance
Fully compliant with IMO shipping standards. Pre-shipment inspection and moisture indicators included.
Do you provide samples?
Yes, for regular sizes sample is free, buyer need to pay freight cost.
How can I get a quotation?
You can leave us message, and we will reply in time. And you can also find our contact details on the Contact page.
How long is the delivery time?
It depends on the order quantity, normally the delivery time takes around 15-30 working days. Please kindly contact us before ordering.
